Floor-mounted jib crane for suspending portable spot welding guns with full three-axis movement over a circular work area. Capacity up to 1,000 lbs; standard spans to 16 ft with 360-degree rotation. Most units bolt directly to existing floors.
The floor-mounted jib crane suspends a portable spot welding gun over a circular work area. The boom rotates a full 360 degrees around the mast while a trolley travels along the boom; paired with a properly sized tool balancer, the system delivers fluid movement through all three axes of motion. Capacity reaches up to 1,000 lbs with standard spans to 16 ft, and the crane is designed to support tool balancers, air balancers, vacuum lifters, and hoists.
A bridge rail is preferable for moving heavier loads around a workstation, but a jib crane is often the best fit where ceiling obstructions prevent installation of a ceiling-mounted bridge rail and the need to keep the floor clear rules out a floor-mounted bridge rail’s runway supports — the jib requires only a single mast at the center of its coverage circle. See our other suspension options to find the right fit for your building, and look through our portable spot welding guns to find the right gun for your project.
Jib crane systems are configured to your application. Add this item to your quote, and include the following in the order notes at checkout so we can spec your system accurately:
| Maximum Capacity (lbs) | 1000 |
|---|---|
| Max Span (ft) | 16 |
| Rotation | 360° |
| Travel | Three-axis (with tool balancer) |
| Mounting | Floor-Mounted |
